Rinnai Condensing 24E External water heater is a room sealed, wall hung, LPG or natural gas fired continuous flow water heater. Rinnai Condensing 24E External water heater is capable of supplying in excess of 833 litres per hour raised 50˚C making it an ideal choice for high capacity light commercial to large industrial system specifications as up to 25 units can be cascaded to supply any specification.

Rinnai Condensing 24E External range incorporates patented down firing pre-mix burner technology that ensure the appliances produce less than 20ppm NOx, future proofing the systems against legislative changes.

Installation External wall mounted
Height 565.2mm
Width 351mm
Depth 219.9mm
Weight 18kg
Exhaust system Forced exhaust
Temperature Range 37°C – 65°C
Ignition method Direct electronic
Gas consumption Propane 2.8kW – 58kW max
Hot water delivery capacity 26L/min raised 25°C
Min operating water flow 2L/min
Nominal operating pressure 1 – 10 bar
Power supply 230V AC 50Hz 1ph
Electric consumption (remote/standby/antifrost) 67/2/104 Watts
